> THK RB Slim Type Crossed Roller Bearing
RB 3510 inner ring rotation crossed roller bearing 35mm bore
- Structure:Crossed Roller Bearing
- Gear teeth: without
- Seals type:double seals
- Material: 52100/100Cr6/GCr15
- Product description: RB 3510 inner ring rotation crossed roller bearing 35mm bore has has integrated inner ring and separable outer ring(fixed by screw), thin section(slim type), suited for where space is limited, and inn
Product introduction
RB 3510 inner ring rotation crossed roller bearing 35mm bore
structure: crossed roller bearing, integrated inner ring with split oute ring, no gear teeth.
d: 35mm
D: 60mm
B: 10mm
C: 7.64kN
Co: 9.12kN
Mass: 0.13kg
RB series crossed roller bearing provides high and stable running accuracy, suited for precision detecting instrument, robot joints, direct drive torque motor, high-precision turntable, etc.
| Model No. | d (mm) | D (mm) | B (mm) | C (KN) | Co (KN) | kg |
| RB 2008 | 20 | 36 | 8 | 3.23 | 3.1 | 0.04 |
| RB 2508 | 25 | 41 | 8 | 3.63 | 3.83 | 0.05 |
| RB 3010 | 30 | 55 | 10 | 7.35 | 8.36 | 0.12 |
| RB 3510 | 35 | 60 | 10 | 7.64 | 9.12 | 0.13 |
| RB 4010 | 40 | 65 | 10 | 8.33 | 10.6 | 0.16 |
| RB 4510 | 45 | 70 | 10 | 8.62 | 11.3 | 0.17 |
| RB 5013 | 50 | 80 | 13 | 16.7 | 20.9 | 0.27 |
| RB 6013 | 60 | 90 | 13 | 18 | 24.3 | 0.3 |
| RB 7013 | 70 | 100 | 13 | 19.4 | 27.7 | 0.35 |
| RB 8016 | 80 | 120 | 16 | 30.1 | 42.1 | 0.7 |
| RB 9016 | 90 | 130 | 16 | 31.4 | 45.3 | 0.75 |
| RB 10016 | 100 | 140 | 16 | 31.7 | 48.6 | 0.83 |
| RB 10020 | 100 | 150 | 20 | 33.1 | 50.9 | 1.45 |
| RB 11012 | 110 | 135 | 12 | 12.5 | 24.1 | 0.4 |
| RB 11015 | 110 | 145 | 15 | 23.7 | 41.5 | 0.75 |
| RB 11020 | 110 | 160 | 20 | 34 | 54 | 1.56 |
| RB 12016 | 120 | 150 | 16 | 24.2 | 43.2 | 0.72 |
| RB 12025 | 120 | 180 | 25 | 66.9 | 100 | 2.62 |
| RB 13015 | 130 | 160 | 15 | 25 | 46.7 | 0.72 |
| RB 13025 | 130 | 190 | 25 | 69.5 | 107 | 2.82 |
| RB 14016 | 140 | 175 | 16 | 25.9 | 50.1 | 1 |
| RB 14025 | 140 | 200 | 25 | 74.8 | 121 | 2.96 |
| RB 15013 | 150 | 180 | 13 | 27 | 53.5 | 0.68 |
| RB 15025 | 150 | 210 | 25 | 76.8 | 128 | 3.16 |
| RB 15030 | 150 | 230 | 30 | 100 | 156 | 5.3 |
| RB 16025 | 160 | 220 | 25 | 81.7 | 135 | 3.14 |
| Model No. | d (mm) | D (mm) | B (mm) | C (KN) | Co (KN) | kg |
| RB 17020 | 170 | 220 | 20 | 29 | 62.1 | 2.21 |
| RB 18025 | 180 | 240 | 25 | 84 | 143 | 3.44 |
| RB 19025 | 190 | 240 | 25 | 41.7 | 82.9 | 2.99 |
| RB 20025 | 200 | 260 | 25 | 84.2 | 157 | 4 |
| RB 20030 | 200 | 280 | 30 | 114 | 200 | 6.7 |
| RB 20035 | 200 | 295 | 35 | 151 | 252 | 9.6 |
| RB 22025 | 220 | 280 | 25 | 92.3 | 171 | 4.1 |
| RB 24025 | 240 | 300 | 25 | 68.3 | 145 | 4.5 |
| RB 25025 | 250 | 310 | 25 | 69.3 | 150 | 5 |
| RB 25030 | 250 | 330 | 30 | 126 | 244 | 8.1 |
| RB 25040 | 250 | 355 | 40 | 195 | 348 | 14.8 |
| RB 30025 | 300 | 360 | 25 | 76.3 | 178 | 5.9 |
| RB 30035 | 300 | 395 | 35 | 183 | 367 | 13.4 |
| RB 30040 | 300 | 405 | 40 | 212 | 409 | 17.2 |
| RB 35020 | 350 | 400 | 20 | 54.1 | 143 | 3.9 |
| RB 40035 | 400 | 480 | 35 | 156 | 370 | 14.5 |
| RB 40040 | 400 | 510 | 40 | 241 | 531 | 23.5 |
| RB 45025 | 450 | 500 | 25 | 61.7 | 182 | 6.6 |
| RB 50025 | 500 | 550 | 25 | 65.5 | 201 | 7.3 |
| RB 50040 | 500 | 600 | 40 | 239 | 607 | 26 |
| RB 50050 | 500 | 625 | 50 | 267 | 653 | 41.7 |
| RB 60040 | 600 | 700 | 40 | 264 | 721 | 29 |
| RB 70045 | 700 | 815 | 45 | 281 | 836 | 46 |
| RB 80070 | 800 | 950 | 70 | 468 | 1330 | 105 |
| RB 90070 | 900 | 1050 | 70 | 494 | 1490 | 120 |
| RB 1000110 | 1000 | 1250 | 110 | 1220 | 3220 | 360 |
| RB 1250110 | 1250 | 1500 | 110 | 1350 | 3970 | 440 |
| Model No. | d (mm) | D (mm) | B (mm) | C (KN) | Co (KN) | kg |
Custom bearing configurations available, please contact us for details.
