> THK RB Slim Type Crossed Roller Bearing
RB 14016 Crossed Roller Bearing separable outer ring type
- Structure:Crossed Roller Bearing
- Gear teeth: without
- Seals type:double seals
- Material: 52100/100Cr6/GCr15
- Product description: RB 14016 Crossed Roller Bearing has has integrated inner ring and separable outer ring(fixed by screw), thin section(slim type), suited for where space is limited, and inner ring running accuracy is r
Product introduction
RB 14016 Crossed Roller Bearing separable outer ring type
d: 140mm
D: 175mm
B: 16mm
C: 25.9kN
Co: 50.1kN
Mass: 1kg
RB 14016 Crossed Roller Bearing has integrated inner ring and separable outer rings(fixed by screw), it's thin section(slim type), suited for where space is limited, and inner ring running accuracy is required.
| Model No. | d (mm) | D (mm) | B (mm) | C (KN) | Co (KN) | kg |
| RB 2008 | 20 | 36 | 8 | 3.23 | 3.1 | 0.04 |
| RB 2508 | 25 | 41 | 8 | 3.63 | 3.83 | 0.05 |
| RB 3010 | 30 | 55 | 10 | 7.35 | 8.36 | 0.12 |
| RB 3510 | 35 | 60 | 10 | 7.64 | 9.12 | 0.13 |
| RB 4010 | 40 | 65 | 10 | 8.33 | 10.6 | 0.16 |
| RB 4510 | 45 | 70 | 10 | 8.62 | 11.3 | 0.17 |
| RB 5013 | 50 | 80 | 13 | 16.7 | 20.9 | 0.27 |
| RB 6013 | 60 | 90 | 13 | 18 | 24.3 | 0.3 |
| RB 7013 | 70 | 100 | 13 | 19.4 | 27.7 | 0.35 |
| RB 8016 | 80 | 120 | 16 | 30.1 | 42.1 | 0.7 |
| RB 9016 | 90 | 130 | 16 | 31.4 | 45.3 | 0.75 |
| RB 10016 | 100 | 140 | 16 | 31.7 | 48.6 | 0.83 |
| RB 10020 | 100 | 150 | 20 | 33.1 | 50.9 | 1.45 |
| RB 11012 | 110 | 135 | 12 | 12.5 | 24.1 | 0.4 |
| RB 11015 | 110 | 145 | 15 | 23.7 | 41.5 | 0.75 |
| RB 11020 | 110 | 160 | 20 | 34 | 54 | 1.56 |
| RB 12016 | 120 | 150 | 16 | 24.2 | 43.2 | 0.72 |
| RB 12025 | 120 | 180 | 25 | 66.9 | 100 | 2.62 |
| RB 13015 | 130 | 160 | 15 | 25 | 46.7 | 0.72 |
| RB 13025 | 130 | 190 | 25 | 69.5 | 107 | 2.82 |
| RB 14016 | 140 | 175 | 16 | 25.9 | 50.1 | 1 |
| RB 14025 | 140 | 200 | 25 | 74.8 | 121 | 2.96 |
| RB 15013 | 150 | 180 | 13 | 27 | 53.5 | 0.68 |
| RB 15025 | 150 | 210 | 25 | 76.8 | 128 | 3.16 |
| RB 15030 | 150 | 230 | 30 | 100 | 156 | 5.3 |
| RB 16025 | 160 | 220 | 25 | 81.7 | 135 | 3.14 |
| Model No. | d (mm) | D (mm) | B (mm) | C (KN) | Co (KN) | kg |
| RB 17020 | 170 | 220 | 20 | 29 | 62.1 | 2.21 |
| RB 18025 | 180 | 240 | 25 | 84 | 143 | 3.44 |
| RB 19025 | 190 | 240 | 25 | 41.7 | 82.9 | 2.99 |
| RB 20025 | 200 | 260 | 25 | 84.2 | 157 | 4 |
| RB 20030 | 200 | 280 | 30 | 114 | 200 | 6.7 |
| RB 20035 | 200 | 295 | 35 | 151 | 252 | 9.6 |
| RB 22025 | 220 | 280 | 25 | 92.3 | 171 | 4.1 |
| RB 24025 | 240 | 300 | 25 | 68.3 | 145 | 4.5 |
| RB 25025 | 250 | 310 | 25 | 69.3 | 150 | 5 |
| RB 25030 | 250 | 330 | 30 | 126 | 244 | 8.1 |
| RB 25040 | 250 | 355 | 40 | 195 | 348 | 14.8 |
| RB 30025 | 300 | 360 | 25 | 76.3 | 178 | 5.9 |
| RB 30035 | 300 | 395 | 35 | 183 | 367 | 13.4 |
| RB 30040 | 300 | 405 | 40 | 212 | 409 | 17.2 |
| RB 35020 | 350 | 400 | 20 | 54.1 | 143 | 3.9 |
| RB 40035 | 400 | 480 | 35 | 156 | 370 | 14.5 |
| RB 40040 | 400 | 510 | 40 | 241 | 531 | 23.5 |
| RB 45025 | 450 | 500 | 25 | 61.7 | 182 | 6.6 |
| RB 50025 | 500 | 550 | 25 | 65.5 | 201 | 7.3 |
| RB 50040 | 500 | 600 | 40 | 239 | 607 | 26 |
| RB 50050 | 500 | 625 | 50 | 267 | 653 | 41.7 |
| RB 60040 | 600 | 700 | 40 | 264 | 721 | 29 |
| RB 70045 | 700 | 815 | 45 | 281 | 836 | 46 |
| RB 80070 | 800 | 950 | 70 | 468 | 1330 | 105 |
| RB 90070 | 900 | 1050 | 70 | 494 | 1490 | 120 |
| RB 1000110 | 1000 | 1250 | 110 | 1220 | 3220 | 360 |
| RB 1250110 | 1250 | 1500 | 110 | 1350 | 3970 | 440 |
| Model No. | d (mm) | D (mm) | B (mm) | C (KN) | Co (KN) | kg |
RB slim type crossed roller bearing provides high and stable running accuracy, suited for precision detecting instrument, robot joints, direct drive torque motor, high-precision turntable, etc.
