THK RA7008 crossed roller bearing 70*86*8mm
- Structure: cross roller bearing
- Gear teeth: without
- Sealing: NBR
- Material: 52100/100Cr6/GCr15
- Product description: THK RA7008 crossed roller bearing 70*86*8mm has compact inner ring with separable outer ring, it's ultra-thin type and has the feature of light weight and high rigidity
Product introduction
THK RA7008 crossed roller bearing 70*86*8mm
![]() |
d | 70 mm |
D | 86 mm | |
B | 8 mm | |
Cr | 5.98 kN | |
C0r |
9.8 kN |
|
Mass |
0.1 kg |
RIGIA THK type THK RA7008 crossed roller bearing 70*86*8mm has high rigidity, loading capacity and rotation accuracy. It's ultra-thin and has integrated inner ring and separable outer ring, suited for where light weight, compact design are required, such as the swiveling units of industrial robot or manipulators.
More RA series cross roller bearing models:
Model No. | d (mm) | D (mm) | B (mm) | Cr (kN) | Cor (kN) | Mass(kg) |
RA5008 | 55 | 66 | 8 | 5.1 | 7.19 | 0.08 |
RA6008 | 60 | 76 | 8 | 5.68 | 8.68 | 0.09 |
RA7008 | 70 | 86 | 8 | 5.98 | 9.8 | 0.1 |
RA8008 | 80 | 96 | 8 | 6.37 | 11.3 | 0.11 |
RA9008 | 90 | 106 | 8 | 6.76 | 12.4 | 0.12 |
RA10008 | 100 | 116 | 8 | 7.15 | 13.9 | 0.14 |
RA11008 | 110 | 126 | 8 | 7.45 | 15 | 0.15 |
RA12008 | 120 | 136 | 8 | 7.84 | 16.5 | 0.17 |
RA13008 | 130 | 146 | 8 | 7.94 | 17.6 | 0.18 |
RA14008 | 140 | 156 | 8 | 8.33 | 19.1 | 0.19 |
RA15008 | 150 | 166 | 8 | 8.82 | 20.6 | 0.2 |
RA16013 | 160 | 186 | 13 | 23.3 | 44.9 | 0.59 |
RA17013 | 170 | 196 | 13 | 23.5 | 46.5 | 0.64 |
RA18013 | 180 | 206 | 13 | 24.5 | 49.8 | 0.68 |
RA19013 | 190 | 216 | 13 | 24.9 | 51.5 | 0.69 |
RA20013 | 200 | 226 | 13 | 25.8 | 54.7 | 0.71 |
To learn more about our company or get the Installation Instructions of THK RA7008 crossed roller bearing 70*86*8mm regarding the installation size, weight, basic dynamic load rating, load, limiting speed, and clearance, please contact us. Drawing and sample of THK RA7008 crossed roller bearing 70*86*8mm are available upon request.
