> IMO 120 Untoothed Ball Slewing Rings
10-20 0741/0-32042 ball slewing rings 25x33.4x2.205''
- Structure:four point contact ball slewing bearing
- Gear teeth: without
- Seals type:double seals
- Material: 52100/100Cr6/GCr15
- Product description: 10-20 0741/0-32042 ball slewing rings 25x33.4x2.205'' is four point contact ball bearing, has no gear teeth, with mounting holes on inner and outer rings. Frequently used in wind energy turbines, cran
Product introduction
10-20 0741/0-32042 ball slewing rings 25x33.4x2.205''
structure: four point contact ball bearing, no gear teeth, with mounting holes on inner/outer rings.
| Part Number | Da (inch/mm) | di(inch/mm) | Width(inch/mm) | Weight(lb/kg) |
| 10-20 0311/0-32002 | 17 | 7.5 | 2.205 | 46 |
| 431.8 | 190.5 | 56 | 21 | |
| 10-20 0413/0-32012 | 20.4 | 12 | 2.205 | 64 |
| 518.16 | 304.8 | 56 | 29 | |
| 10-20 0541/0-32022 | 25.5 | 17 | 2.205 | 82 |
| 647.7 | 431.8 | 56 | 37 | |
| 10-20 0641/0-32032 | 29.5 | 21 | 2.205 | 97 |
| 749.3 | 533.4 | 56 | 44 | |
| 10-20 0741/0-32042 | 33.4 | 25 | 2.205 | 115 |
| 848.36 | 635 | 56 | 52 | |
| 10-20 0841/0-32052 | 37.4 | 28.83 | 2.205 | 130 |
| 949.96 | 732.28 | 56 | 59 | |
| 10-20 0941/0-32062 | 41.25 | 32.83 | 2.205 | 146 |
| 1047.75 | 833.88 | 56 | 66 | |
| 10-20 1091/0-32072 | 47.18 | 38.75 | 2.205 | 170 |
| 1198.372 | 984.25 | 56 | 77 |
10-20 0741/0-32042 ball slewing rings 25x33.4x2.205''and other IMO 120 series slewing bearing applications:
wind energy turbines, cranes, construction machinery, mechanical, engineering and other special purpose machinery, such as shipboard cranes, harbour cranes, railway slewing cranes, manlift platforms, mobile cranes, rotating carousels, etc.
PREVIOUS：10-20 0641/0-32032 ball slewing ring 21inch bore
NEXT：10-20 0841/0-32052 ball slewing rings
