> IMO 120 Untoothed Ball Slewing Rings
10-20 0311/0-32002 ball slewing rings untoothed
- Structure:four point contact ball slewing bearing
- Gear teeth: without
- Seals type:double seals
- Material: 52100/100Cr6/GCr15
- Product description: 10-20 0311/0-32002 ball slewing rings untoothed is four point contact ball slewing bearing, without gear teeth, with mounting holes on inner and outer rings.
Product introduction
10-20 0311/0-32002 ball slewing rings untoothed
structure: four point contact ball bearing, no gear teeth, with mounting holes on inner/outer rings.
| Part Number | Da (inch/mm) | di(inch/mm) | Width(inch/mm) | Weight(lb/kg) |
| 10-20 0311/0-32002 | 17 | 7.5 | 2.205 | 46 |
| 431.8 | 190.5 | 56 | 21 | |
| 10-20 0413/0-32012 | 20.4 | 12 | 2.205 | 64 |
| 518.16 | 304.8 | 56 | 29 | |
| 10-20 0541/0-32022 | 25.5 | 17 | 2.205 | 82 |
| 647.7 | 431.8 | 56 | 37 | |
| 10-20 0641/0-32032 | 29.5 | 21 | 2.205 | 97 |
| 749.3 | 533.4 | 56 | 44 | |
| 10-20 0741/0-32042 | 33.4 | 25 | 2.205 | 115 |
| 848.36 | 635 | 56 | 52 | |
| 10-20 0841/0-32052 | 37.4 | 28.83 | 2.205 | 130 |
| 949.96 | 732.28 | 56 | 59 | |
| 10-20 0941/0-32062 | 41.25 | 32.83 | 2.205 | 146 |
| 1047.75 | 833.88 | 56 | 66 | |
| 10-20 1091/0-32072 | 47.18 | 38.75 | 2.205 | 170 |
| 1198.372 | 984.25 | 56 | 77 |
10-20 0311/0-32002 ball slewing rings untoothed and other IMO 120 series slewing bearing applications:
wind energy turbines, cranes, construction machinery, mechanical, engineering and other special purpose machinery.
