  > THK RU TYPE Integrated inner and outer ring Crossed Roller Bearing

•
•
•

Product introduction

	RU297UUC0X-N Crossed Roller Bearing
	d	210 mm
	D	380 mm
	dp	297.3 mm	Roller pitch circle dia.
	B	40 mm
	d1	6 mm
	r/min	2.5 r/min	Rotational speed
	ds (max)	272 mm	Shoulder Height
	Dh (min)	320 mm	Shoulder Height
	Cr	156 KN	Basic static load rating
	Cor	281 KN	Basic dynamic load rating
	Mass	21.3 kg
	PCD1	240 mm
		16-M12 through	Mounnting hole
	PCD2	350 mm
		16-φ14 drilled through,  φ20 counter bore depth 13	Mounnting hole

More RU series crossed roller bearing models:

RU42
RU66
RU85
RU124(G)
RU124X
RU148(G)
RU148X
RU178(G)
RU178X
RU228(G)
RU228X
RU297(G)
RU297X
RU445(G)
RU445X

To learn more about RU297UUC0X-N cross roller bearing please contact us , customized size & structure available.
