  > IKO CRBH Crossed Roller Bearing

•

Product introduction

		CRBH 5013 A Crossed roller bearing
		d	50 mm
		D	80 mm
		B	13 mm
		Cr	17.3 KN	Basic dynamic load rating
		Cor	20.9 KN	Basic static load rating
		Mass	0.29 kg

(A means open type, AUU means sealed on both sides.)

CRBH5013A, CRB5013AUU Cross Roller Bearing belong to IKO Model CRBH series cross roller bearing(with separator). It's ultra-thin type, has integrated inner & outer ring, need housing and flange for fixing during installation.

Features:
CRBH series cross roller bearing has stable rotational precisioin and torque, suited for limited space, and where inner ring and outer ring rotation required.

Open Type	Sealed Type	d (mm)	D (mm)	B (mm)	C (kN)	C0 （kN)	Mass (kg)
CRBH 208 A	CRBH 208 A UU	20	36	8	2.91	2.43	0.04
CRBH 258 A	CRBH 258 A UU	25	41	8	3.12	2.81	0.05
CRBH 3010 A	CRBH 3010 A UU	30	55	10	7.6	8.37	0.12
CRBH 3510 A	CRBH 3510 A UU	35	60	10	7.9	9.13	0.13
CRBH 4010 A	CRBH 4010 A UU	40	65	10	8.61	10.6	0.15
CRBH 4510 A	CRBH 4510 A UU	45	70	10	8.86	11.3	0.16
CRBH 5013 A	CRBH 5013 A UU	50	80	13	17.3	20.9	0.29
CRBH 6013 A	CRBH 6013 A UU	60	90	13	18.8	24.3	0.33
CRBH 7013 A	CRBH 7013 A UU	70	100	13	20.1	27.7	0.38
CRBH 8016 A	CRBH 8016 A UU	80	120	16	32.1	43.4	0.74
CRBH 9016 A	CRBH 9016 A UU	90	130	16	33.1	46.8	0.81
CRBH 10020 A	CRBH 10020 A UU	100	150	20	50.9	72.2	1.45
CRBH 11020 A	CRBH 11020 A UU	110	160	20	52.4	77.4	1.56
CRBH 12025 A	CRBH 12025 A UU	120	180	25	73.4	108	2.62
CRBH 13025 A	CRBH 13025 A UU	130	190	25	75.9	115	2.82
CRBH 14025 A	CRBH 14025 A UU	140	200	25	81.9	130	2.96
CRBH 15025 A	CRBH 15025 A UU	150	210	25	84.3	138	3.16
CRBH 20025 A	CRBH 20025 A UU	200	260	25	92.3	169	4
CRBH 25025 A	CRBH 25025 A UU	250	310	25	102	207	4.97
